Stahlwille 58255004 725B 1/4" Drive insert tool, size 4, 9x12 mm
Stahlwille 58255004 725B 1/4" Drive insert tool, size 4, 9x12 mm
Stahlwille 58255004 725B 1/4" Drive insert tool, size 4, 9x12 mm
Stahlwille 58255004 725B 1/4" Drive insert tool, size 4, 9x12 mm
Stahlwille logo

Stahlwille 58255004 725B 1/4" Drive insert tool, size 4, 9x12 mm

$113.38 USD & FREE Shipping.
/
  • for torque wrenches with interchangeable insert system
  • reversible
  • with internal hex, 1/4" or 5/16", DIN 3126 / ISO 1173 D 6.3 or D8
  • for direct mounting of bits with 1/4" or 5/16" external hex C 6.3 or C 8 (size 4: 22 teeth, size 5: 30 teeth)
  • hex with collar-thrust spring
Overview

These bit ratchet insert adapters are designed for torque wrenches with an interchangeable insert system and feature a reversible mechanism for versatile use. They have an internal hex of 1/4" or 5/16" (DIN 3126 / ISO 1173 D 6.3 or D8) for direct mounting of bits with 1/4" or 5/16" external hex C 6.3 or C 8 (size 4: 22 teeth, size 5: 30 teeth). Equipped with a collar-thrust spring, the bits are easy to insert, lock securely, and can be easily removed. They also accommodate hex bits with a wide groove (Form E, DIN 3126 / ISO 1173), ensuring reliable and efficient operation.

Brand img

Stahlwille 58255004 725B 1/4" Drive insert tool, size 4, 9x12 mm

You may also like
Specifications
General Information
Brand
Stahlwille
Product Type
Torque Wrenches
Packaging
Bulk
Country of Origin
Germany
UPC
4018754140794
California Residents
Proposition 65 Warning
Part Number
58255004
Physical Characteristics
Material
Alloy Steel
Length
48 mm
Width
26 mm
Height
13 mm
Weight
0.23 kg
0.51 lb
Details
Wrench Type
Torque
Size
4
Features
for torque wrenches with interchangeable insert system
reversible
with internal hex, 1/4" or 5/16", DIN 3126 / ISO 1173 D 6.3 or D8
for direct mounting of bits with 1/4" or 5/16" external hex C 6.3 or C 8 (size 4: 22 teeth, size 5: 30 teeth)
hex with collar-thrust spring
bits are easy to insert, lock securely into place, and can be easily pulled out again; also hex with wide groove (Form E, DIN 3126 / ISO 1173)
Drive Connector Size
1/4 Inches
About Manufacturer
Stahlwille

While there are many brands of high quality German tools, few are as recognized as Stahlwille. Stahlwille Tools is well known not just for automotive tools, but they’re a brand widely used by the aerospace industry. One of Stahlwille’s contributions to aerospace was the “Tool Control” System which uses bright colors in the storage case that show only when a tool is missing. Stahlwille has also led innovation in aerospace applications by creating tools like the Anti Slip Drive, the Spline Drive the Quick Release and many more. The quality of Stahlwille Tools is among the best, anything less would be disastrous for those in aerospace.
