Dimensions and Specifications
Expanded Inner Diameter
0.187 in
Expanded Inner Diameter (Metric)
4.75 mm
Inner Diameter After Shrink (Imperial)
0.062 in
Inner Diameter After Shrink (Metric)
1.57 mm
Inner Diameter Before Shrink (Imperial)
0.187 in
Inner Diameter Before Shrink (Metric)
4.75 mm
Maximum Operating Temperature (Celsius)
110 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Operating Temperature Range (Celsius)
-55 °C to 110 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Recovered Inner Diameter
0.062 in
Recovered Inner Diameter (Metric)
1.5748 mm
Tensile Strength (Imperial)
2100 Pound-Force Per Square Inch
Width
11.87 in
30.16 cm
Height
8.75 in
22.23 cm
Length
15.37 in
39.05 cm
Volume
1597.51 cubic inch
26178.53 cm3
Weight
9.48 lb
4.3 kg
