Stahlwille 50010030 14mm x 18mm Manoskop Torque Wrench

$260.89 USD & FREE Shipping.
/
Extended Handling May Be Required
  • clicking type with dual stop signal
  • for work on assembly lines or for repetitive production tasks.
  • no adjustment scale; therefore adjustment with test equipment is required, e.g. with the STAHLWILLE test devices No. 7707 W, SmartCheck or the perfectControl® calibration system No. 7794, or calibration systems No. 7706. 7791)
  • with holder for interchangeable insert tools
  • particularly slim design
Overview
This clicking type torque wrench features a dual stop signal and is suitable for work on assembly lines or repetitive production tasks. It has no adjustment scale; therefore, adjustment with test equipment is required, such as STAHLWILLE test devices No. 7707 W, SmartCheck, the perfectControl® calibration system No. 7794, or calibration systems No. 7706 and 7791 It is equipped with a holder for interchangeable insert tools and features a particularly slim design. The handle and shaft are made of square steel pipe. Further loading after clicking, or loads in the opposite direction of operation (up to the maximum measurement range of the torque wrench), do not affect the trigger mechanism, protecting it from damage. Counter-clockwise tightening is possible by turning the insert tool over It can be supplied pre-set at a defined torque value with certification (additional charge applies). Accuracy is ± 4%.
Brand img

Stahlwille 50010030 14mm x 18mm Manoskop Torque Wrench

You may also like
Specifications
General Information
Brand
Stahlwille
Product Type
Torque Wrenches
Packaging
Bulk
Country of Origin
Germany
UPC
4018754031658
California Residents
Proposition 65 Warning
Part Number
50010030
Physical Characteristics
Material
Steel
Length
609 mm
Width
28 mm
Height
24 mm
Weight
0.78 kg
1.71 lb
Details
Wrench Type
Torque
Torque Range ft lbs
40ft lb - 220ft lb
Torque Range Nm
60Nm - 300Nm
Type
Square
Size
30 mm
Features
clicking type with dual stop signal
for work on assembly lines or for repetitive production tasks.
no adjustment scale; therefore adjustment with test equipment is required, e.g. with the STAHLWILLE test devices No. 7707 W, SmartCheck or the perfectControl® calibration system No. 7794, or calibration systems No. 7706. 7791)
with holder for interchangeable insert tools
particularly slim design
handle and shaft made of square steel pipe
Further loading after clicking or loads in the opposite direction of operation (up to the max. measurement range of the torque wrench) do not affect the trigger mechanism, which protects it from damage
counter-clockwise tightening by turning the insert tool over
can be supplied pre-set at defined torque value and with certification (additional charge applies)
accuracy ± 4%
About Manufacturer
Stahlwille

While there are many brands of high quality German tools, few are as recognized as Stahlwille. Stahlwille Tools is well known not just for automotive tools, but they’re a brand widely used by the aerospace industry. One of Stahlwille’s contributions to aerospace was the “Tool Control” System which uses bright colors in the storage case that show only when a tool is missing. Stahlwille has also led innovation in aerospace applications by creating tools like the Anti Slip Drive, the Spline Drive the Quick Release and many more. The quality of Stahlwille Tools is among the best, anything less would be disastrous for those in aerospace.
