Standard Abrasives Silicon Carbide Cartridge Roll, 707845, CR-ST, 80
Standard Abrasives Silicon Carbide Cartridge Roll, 707845, CR-ST, 80
Standard Abrasives Silicon Carbide Cartridge Roll, 707845, CR-ST, 80

Standard Abrasives Silicon Carbide Cartridge Roll, 707845, CR-ST, 80

Regular price
/

$105.99 USD & FREE Shipping.
  • Ideal for grinding and deburring on ferrous and non-ferrous metals
  • Small size enables operators to reach tight spots with high speed
  • Multi-layer design continually reveals fresh abrasive for longevity and consistent cut
  • Super sharp silicon carbide cuts through hard-to-grind metals and softer surfaces
  • Versatile range of sizes and grades are designed to meet specific project needs
  • Arbor hole accommodates mandrel tool attachment for use with various high speed tools
Overview
In coarse grades, the Standard Abrasives Silicon Carbide Cartridge Roll is used for high-speed grinding and deburring on all metals, as well as glass and composites. Its small size and shape enable it to reach into holes and diameters of machined parts or deburr irregular surfaces and contours. Super sharp silicon carbide suits hard-to-grind metals such as titanium, as well as softer surfaces.

Recommended Applications
Choose a Standard Abrasives™ Silicon Carbide Cartridge Roll when you need to grind or deburr hard-to-reach areas of the workpiece. It is ideal for getting into grooves, slots, threads or channels, punched or drilled holes, and contoured surfaces such as car parts. Combining an aggressive cut with durability makes it a great solution for edge breaking and removal of machine tool marks or flash.

Cartridge rolls are either straight or tapered. The cylindrical shape of the straight cartridge roll passes easily over and into irregular contours, while the tapered roll excels at reaching into corners and very tight diameters such as punched or drilled holes.

Running a Cartridge Roll on a High-Speed Tool
The cartridge roll has an arbor hole to accommodate a mandrel tool attachment (sold separately), which attaches to a rotary tool such as a die grinder or drill. The mandrel should have a pilot length no less than 1/2˝ shorter than the length of the cartridge roll.

Super Sharp Silicon Carbide Leaves a Fine Finish
Silicon Carbide is harder and sharper than either aluminum oxide or zirconia alumina. It is most commonly used for low-pressure applications such as paint prep and the final stages of whitewood sanding. While it may have a shorter life than aluminum oxide, it produces a superior finish and should be used when a fine scratch pattern is desired.

Benefits of a Multi-Layer Design
Seemingly small, these cartridge rolls conquer big challenges when space gets tight. The multi-layer, multi-wear design of Standard Abrasives™ Zirconia Cartridge Roll keeps it cutting sharp and helps it withstand repeated wear. As top layers wear down with use, underlying layers expose fresh mineral, so you get a continuous and consistent cut, part after part. Wrapping multiple layers of the abrasive material around into a roll contributes to its sturdiness and durability.

A resin bond securely anchors mineral to the cloth backing – also enhancing the abrasive's toughness and strength. The closed-coat construction means mineral grains cover 100 percent of the cloth backing, so that a smoother, more consistent finish is achieved.

Quality Standard Abrasives™ Solutions for Industrial Applications
The Standard Abrasives brand has supplied quality abrasives to the metalworking industry for over 50 years. Customers rely on our broad offering of high performance products including coated, bonded, and non-woven abrasive lines.

Standard Abrasives Silicon Carbide Cartridge Roll, 707845, CR-ST, 80

Specifications
General Information
Brand
Standard Abrasives™
Bond Type
Resin
Country Of Origin
United States
Sold As
Case
Lead Time
15 days
California Residents
Dimensions and Specifications
Backing Weight
X Weight
Center Hole Diameter (Imperial)
0.125 in
Center Hole Diameter (Metric)
3.175 mm
Grit
80
Overall Diameter (Imperial)
0.5 in
Overall Diameter (Metric)
12.7 mm
Overall Length (Imperial)
1.5 in
Overall Length (Metric)
38.1 mm
Width
6.38 in
16.2 cm
Height
4.69 in
11.9 cm
Length
6.38 in
16.2 cm
Volume
190.58 cubic inch
3123.04 cm3
Weight
14.37 oz
407.3 g
Other Details
Industries
Metalworking
Roll Form
Straight
Sub Industries
Metal Fabrication
Usage Information
Application
Finishing
Equipment - Machines
Die Grinders
Sub Applications
Blending Corners
Equipment Machines
Die Grinders
Material and Composition
Abrasive Material
Silicon Carbide
Backing Material
Cloth
Product Form
Cartridge Roll
Grade
Non Pertinent
Color and Appearance
Product Color
Black
