Dimensions and Specifications
Back Side Adhesive Thickness (Imperial)
3 mil
Back Side Adhesive Thickness (Metric)
0.08 mm
Backing (Carrier) Thickness (Imperial)
0.178 mil
Backing (Carrier) Thickness (Metric)
0.076 mm
Carrier Thickness
0.17847 mil
Carrier Thickness (Metric)
0.08 mm
Core Size (Imperial)
3 in
Core Size (Metric)
76.2 mm
Face Side Adhesive Thickness (Imperial)
3 mil
Face Side Adhesive Thickness (Metric)
0.08 mm
Master Size Length (Metric)
131.7 m
Master Size Width (Metric)
66 cm
Maximum Operating Temperature (Celsius)
49 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
120 Degree Fahrenheit
Minimum Operating Temperature (Celsius)
-40 Degree Celsius
Minimum Operating Temperature (Fahrenheit)
-40 Degree Fahrenheit
Overall Length (Imperial)
36 yd
Overall Length (Metric)
32.91 m
Overall Thickness (Imperial)
3 mil
Overall Width (Imperial)
1 in
Overall Width (Metric)
25.4 mm
Primary Liner Thickness (Imperial)
3.7 mil
Primary Liner Thickness (Metric)
0.09 mm
Total Tape Thickness Without Liner (Imperial)
9 mil
Total Tape Thickness Without Liner (Metric)
0.228 mm
Maximum Operating Temperature Celsius
49.0
Overall Length Imperial
36.0
Volume
52.87 cubic inch
866.39 cm3
Weight
10.44 oz
296 g
