Overview
Features
- Particularly easy to use thanks to short design
- Universal application thanks to connection for insert tools
- Factory preset triggering value as requested
- Accuracy ± 2 % (6391-10: 6%) of set value (in direction of actuation)
- Left tightening with same accuracy possible by reversing the wrench
- Plug-and-socket connection to hold insert tools
- Permanently adjustable value
- Especially suitable for application in industrial series production
- Setting the desired torque value with adjustment wrench 6399 together with HAZET torque tester 7901 E, 7902 E, 7903 E or any other suitable device.
- All wrenches of this series (HAZET 6391-6392) are without a scale and a signal transmitter
- With calibration certificate and serial number
- No turning back: continuous long-term tests on the 5000 series and 6000 series of HAZET torque wrenches have been able to demonstrate that turning them back to the smallest scale value is no longer required
You may also like
Specifications
General Information
Brand
Hazet
Part Number
6391-12V
Product Type
Torque wrench
Packaging
Retail
Country of Origin
Germany
UPC
4000896145850
California Residents
Proposition 65 Warning
Physical Characteristics
Length
124 mm
Width
Head width b: 22 mm
Weight
0.20 kg
0.44 lb
Details
Wrench Type
Torque
Type
Insert square
Size
9 x 12 mm
Features
Tolerance: 2 %
Effective torque wrench length min.-max. I1 mm: 121.00 – 121.00 Nm
Actuating force min.-max. kg: 1.7 – 10.1 kg
Head Thickness a: 17 mm
Head Width b: 22 mm
Effective torque wrench length min.-max. I1 mm: 121.00 – 121.00 Nm
Actuating force min.-max. kg: 1.7 – 10.1 kg
Head Thickness a: 17 mm
Head Width b: 22 mm
Torque Range Nm
2 – 12 Nm
Torque Accuracy
± 2 % of set value (in direction of actuation)
Why would you use this tool for ?
About manufacturer
Hazet Tools are indeed some of the best tools made today, and they have a long tradition of excellence to back them up. Hazet got started in 1868 in Remscheid, Germany making parts for construction, lawnmowers and locks. Hazet has since grown and earned their reputation as the leader in manufacturing automotive tools, pioneering tools specifically made for cars as early as 1913. They further solidified their reputation in automotive tools by developing and making the tool for the iconic Volkswagen Beetles and Porsche 356. Hazet Tools and automotive work are the perfect match!
