Dimensions and Specifications
Back Side Adhesive Thickness (Imperial)
2.9 mil
Back Side Adhesive Thickness (Metric)
0.07 mm
Backing (Carrier) Thickness (Imperial)
0.095 mil
Backing (Carrier) Thickness (Metric)
0.03 mm
Carrier Thickness
0.09514 mil
Carrier Thickness (Metric)
0.03 mm
Core Size (Imperial)
3 in
Core Size (Metric)
76.2 mm
Face Side Adhesive Thickness (Imperial)
1.6 mil
Face Side Adhesive Thickness (Metric)
0.04 mm
Master Size Length (Metric)
98.8 m
Master Size Width (Metric)
122 cm
Maximum Operating Temperature (Celsius)
121 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
250 Degree Fahrenheit
Minimum Operating Temperature (Fahrenheit)
-40 Degree Fahrenheit
Overall Length (Imperial)
36 yd
Overall Length (Metric)
33 m
Overall Thickness (Imperial)
5.5 mil
Overall Width (Imperial)
3 in
Overall Width (Metric)
76.2 mm
Primary Liner Thickness (Imperial)
4.2 mil
Primary Liner Thickness (Metric)
0.11 mm
Secondary Liner Thickness (Imperial)
2.9 mil
Secondary Liner Thickness (Metric)
0.07 mm
Total Tape Thickness Without Liner (Imperial)
5.5 mil
Total Tape Thickness Without Liner (Metric)
0.14 mm
Maximum Operating Temperature Celsius
121.0
Overall Length Imperial
36.0
Width
13.39 in
34 cm
Height
11.61 in
29.5 cm
Length
13.39 in
34 cm
Volume
34.1 dm3
Weight
26.9 lb
12.2 kg
