Dimensions and Specifications
Cable Size Range
2-4/0 AWG
Conductor Sizes (Imperial)
2/0 AWG
Conductor Sizes (Metric)
120 mm²
Expanded Inner Diameter
1.1 in
Expanded Inner Diameter (Metric)
27.9 mm
Inner Diameter After Shrink (Imperial)
0.2 in
Inner Diameter After Shrink (Metric)
0.508 cm²
Inner Diameter Before Shrink (Imperial)
0.8 in
Inner Diameter Before Shrink (Metric)
2.032 cm²
Maximum Conductor Size (Imperial)
4/0 AWG
Maximum Conductor Size (Metric)
120 mm²
Maximum Operating Temperature (Celsius)
110 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Maximum Voltage Rating
1 kV
Minimum Conductor Size (Imperial)
2 AWG
Minimum Conductor Size (Metric)
35 mm²
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to +110 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
48 in
Overall Length (Metric)
1219 mm
Recovered Inner Diameter
0.37 in
Recovered Inner Diameter (Metric)
9.4 mm
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
Voltage
1 kV
Voltage Rating
UL Rated to 600 V (Shall not exceed 1 kV)
Maximum Conductor Size Imperial
4/0 AWG
Maximum Conductor Size Metric
120 mm²
Minimum Conductor Size Imperial
2 AWG
Minimum Conductor Size Metric
35 mm²
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
48.0
Width
7.46 in
18.95 cm
Height
7.38 in
18.75 cm
Length
51.02 in
129.59 cm
Volume
2808.81 cubic inch
46028.17 cm3
Weight
179.2 oz
5080.24 g
