Dimensions and Specifications
Cable Size Range
2-4/0 AWG
Expanded Inner Diameter
1.1 in
Expanded Inner Diameter (Metric)
27.9 mm
Inner Diameter After Shrink (Imperial)
0.37 in
Inner Diameter After Shrink (Metric)
0.94 cm²
Inner Diameter Before Shrink (Imperial)
1.1 in
Inner Diameter Before Shrink (Metric)
2.794 cm²
Maximum Operating Temperature (Celsius)
100 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Maximum Voltage Rating
1 kV
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to -100 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
9 in
Overall Length (Metric)
228.6 mm
Recovered Inner Diameter
0.37 in
Recovered Inner Diameter (Metric)
9.4 mm
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
Voltage
1 kV
Voltage Rating
UL Rated to 600 V (Shall not exceed 1 kV)
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
9.0
Width
16.38 in
41.61 cm
Height
7.75 in
19.69 cm
Length
19.38 in
49.23 cm
Volume
40.32 dm3
Weight
153.6 oz
4354.49 g
