Dimensions and Specifications
Cable Size Range
3/0 AWG-450 kcmil
Expanded Inner Diameter
1.5 in
Expanded Inner Diameter (Metric)
38.1 mm
Inner Diameter After Shrink (Imperial)
0.5 in
Inner Diameter After Shrink (Metric)
1.27 cm²
Inner Diameter Before Shrink (Imperial)
1.5 in
Inner Diameter Before Shrink (Metric)
3.81 cm²
Maximum Conductor Size (Imperial)
450 kcmil
Maximum Conductor Size (Metric)
240 mm²
Maximum Operating Temperature (Celsius)
100 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Maximum Voltage Rating
1 kV
Minimum Conductor Size (Imperial)
3/0 AWG
Minimum Conductor Size (Metric)
95 mm²
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to -100 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
48 in
Overall Length (Metric)
1219 mm
Recovered Inner Diameter
0.5 in
Recovered Inner Diameter (Metric)
12.7 mm
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
Voltage
1 kV
Voltage Rating
UL Rated to 600 V (Shall not exceed 1 kV)
Maximum Conductor Size Imperial
450 kcmil
Maximum Conductor Size Metric
240 mm²
Minimum Conductor Size Imperial
3/0 AWG
Minimum Conductor Size Metric
95 mm²
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
48.0
Width
9.37 in
23.8 cm
Height
9.37 in
23.8 cm
Length
51.14 in
129.9 cm
Volume
4490.16 cubic inch
73580.56 cm3
Weight
20.85 lb
9.46 kg
