Dimensions and Specifications
Cable Size Range
600-1250 kcmil
Expanded Inner Diameter
3 in
Expanded Inner Diameter (Metric)
76.2 mm
Inner Diameter After Shrink (Imperial)
1 in
Inner Diameter After Shrink (Metric)
2.54 cm²
Inner Diameter Before Shrink (Imperial)
3 in
Inner Diameter Before Shrink (Metric)
7.62 cm²
Maximum Conductor Size (Imperial)
1250 kcmil
Maximum Conductor Size (Metric)
633.4 mm²
Maximum Operating Temperature (Celsius)
100 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Maximum Voltage Rating
1 kV
Minimum Conductor Size (Imperial)
600 kcmil
Minimum Conductor Size (Metric)
300 mm²
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to -100 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
48 in
Overall Length (Metric)
1219 mm
Recovered Inner Diameter
1 in
Recovered Inner Diameter (Metric)
25.4 mm
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
Voltage
1 kV
Voltage Rating
UL Rated to 600 V (Shall not exceed 1 kV)
Maximum Conductor Size Imperial
1250 kcmil
Maximum Conductor Size Metric
633.4 mm²
Minimum Conductor Size Imperial
600 kcmil
Minimum Conductor Size Metric
300 mm²
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
48.0
Width
17.36 in
44.1 cm
Height
14.76 in
37.5 cm
Length
50.39 in
128 cm
Volume
211.68 dm3
Weight
37.62 lb
17.06 kg
