Dimensions and Specifications
Cable Size Range
600-1250 kcmil
Expanded Inner Diameter
3 in
Expanded Inner Diameter (Metric)
76.2 mm
Inner Diameter After Shrink (Imperial)
1 in
Inner Diameter After Shrink (Metric)
2.54 cm²
Inner Diameter Before Shrink (Imperial)
3 in
Inner Diameter Before Shrink (Metric)
7.62 cm²
Maximum Operating Temperature (Celsius)
100 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Maximum Voltage Rating
1 kV
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to -100 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
12 in
Overall Length (Metric)
304.8 mm
Recovered Inner Diameter
1 in
Recovered Inner Diameter (Metric)
25.4 mm
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
Voltage
1 kV
Voltage Rating
UL Rated to 600 V (Shall not exceed 1 kV)
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
12.0
Width
0.4 yd
0.37 m
Height
0.28 yd
0.26 m
Length
0.39 yd
0.36 m
Volume
2065.26 cubic inch
33843.53 cm3
Weight
5.3 lb
2.4 kg
