Dimensions and Specifications
Cable Size Range
2.1-4.8 in
Expanded Inner Diameter
6 in
Expanded Inner Diameter (Metric)
152.4 mm
Inner Diameter After Shrink (Imperial)
2.1 in
Inner Diameter After Shrink (Metric)
1.8 mm
Inner Diameter Before Shrink (Imperial)
4.8 in
Inner Diameter Before Shrink (Metric)
6 mm
Maximum Operating Temperature (Celsius)
100 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Maximum Voltage Rating
1 kV
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to -100 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
48 in
Overall Length (Metric)
1219 mm
Recovered Inner Diameter
1.8 in
Recovered Inner Diameter (Metric)
45.7 mm
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
Voltage
1 kV
Voltage Rating
UL Rated to 600 V (Shall not exceed 1 kV)
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
48.0
Width
20.39 in
51.8 cm
Height
25.31 in
64.3 cm
Length
50.47 in
128.2 cm
Volume
427 dm3
Weight
58.9 lb
26.72 kg
